PP700W pistol info.. Mini bullpup donor?
Topic Started: Monday Dec 28 2015, 01:04 PM (17,100 Views)
jameswrx
Bought this the other day, awesome little pistol.

Thought I'd put some pics up, might be of some use if anyone's thinking of a mini 'pup.

If anyone wants other specifics, let me know.

Posted Image

Grip off, 3 hex bolts. Note the two blocks the top bolts secure to.

Posted Image

Posted Image

Hammer spring adjuster, flat driver adjustment and 7mm hex

Posted Image

Posted Image

10mm of thread for the adjuster.

Posted Image

Posted Image
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Posted Image

Posted Image

Posted Image

Posted Image

Posted Image

Posted Image
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Posted Image

Posted Image


Obviously this is just a 'rough' measurement guide to give anyone an idea, please don't take it as gospel. It's more deigned to let you decide if these may be suitable for a mini pup.

Personally I'm thinking a mini Colibri almost. Obviously you'll need a cut out for the swivel BUT regarding the hammer, you could actually bury that under the stock and fit a cocking lever directly to the side of it, so it sticks out the side of the stock and you'd cock it in almost the same movement as cocking a Colibri!

Could be awesome. The air tube and trigger guard has even got a similar look!
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
Nice work James if ican talk one of the Cnc router guys at work to ave a play might just have a look at one of these
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
grumpyoldman
Cracking break down , So it looks from the tape measure like the barrel is 30cm so making a pup out of it could be fine with the power wound up .
I very much like the idea of a mini colibri would not be bothered about a cocking mech just a cut out to access the hammer .
I have a good dig around the net and can not find anything about a regulated version .
Im of to find smk contact details and drop a quick email on the subject .Now hurry up and get a stock made :)
Member Avatar
Cricket
[ *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Cheers Dave, think you'd like it mate. I can't get over how well it shoots. I expected to be cleaning the barrel and such (P10 style) but I've even shot 3 shots through one hole at 6m. I know it's a bit of luck but having put hundreds of shots through a proper target pistol (FAS 6004) I've not had such good results!

Because of the way the spring housing bolts on, there's plenty of option to make a new hammer spring frame and totally change the hammer setup for a more normal rifle one too.
Edited by jameswrx, Monday Dec 28 2015, 02:04 PM.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
jameswrx
30cm is to back of the swivel breech (13mm thick) grumps.

Edited by jameswrx, Monday Dec 28 2015, 02:06 PM.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
any one know where i can get an adapter to fit my fx pump hose. as my hose is a screw end and for the pp700 i need a push fit, would this one fit.

http://www.ebay.co.uk/itm/BEST-Fittings-Quick-Coupler-Socket-Daystate-Official-/250587768485?hash=item3a5831e6a5:m:mQLyrhyxgwAiBVr-6A8FDSA
Edited by bcham, Wednesday Jan 13 2016, 03:08 PM.
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
Yeah that would fit perfect check best fittings for best prices
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
As Dave says, that will fit.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
Dave G
Wednesday Jan 13 2016, 05:18 PM
Yeah that would fit perfect check best fittings for best prices
thanks ordered
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
bcham
i wonder if they will bring a shoulder stock out for this pistol similar to the crosman 1322. No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
Wat about a ratcather stock or mrod stock as it looks a direct copy of the kalibrgun pistol be interesting to see if the Russia's bring anything out to fit
Edited by Dave G, Friday Jan 15 2016, 07:44 PM.
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
There's bound to be something for them, they're going to be popular as some places are doing them for £150!

There's loads of potential for mods on these. Little Bullpup kit would be pretty cool.

I'll be picking up some walnut blanks next week.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
Where they £150 James got some birch maple laminate that might just suffice
Edited by Dave G, Friday Jan 15 2016, 07:44 PM.
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
There's couple places were doing them for that. I know Kirkless guns were and some chap on bbs got the price matched somewhere else. I'd imagine most places can do them for that as a couple of them have.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
That sounds great kirklees isn't far from here
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
Dave G
Got to say S.P.A are coming on leaps and bounds in the airgun market really tempted by one of these wonder what's next tho will there be multi shot versions you think with quality like p12 p10 cp1 now these thing are looking good
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Looking forward to the P15 myself, good times to be a Bullpup lover with all of the developments.

Hopefully next SPA 'pup gets a side cocking lever.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
am i doing something wrong i cant get any air in the pistol . my fx mk3 pump is conneced up,but the gauge on the pump is on zero and the pistol as 100 bar left in the gun, but after pumping over 50 times the pistols still on 100 bar. No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
Is it sealing on the threads of the fill adpters or the orings on the fill adapter been greased
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
bcham
should the pump gauge match the preasure whats left in the gun as the gauge is not moving when pumping it just stays on zero No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
It must be leaking some where mate or it would build up pressure
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Have you done up the bleed screw on the pump lol

Seriously though, if there's no pressure on the pump then there's (like Dave said) a leak between the pump and the O ring on the fill probe. Check all connections back to the pump.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
jameswrx
Saturday Jan 16 2016, 01:35 PM
Have you done up the bleed screw on the pump lol

Seriously though, if there's no pressure on the pump then there's (like Dave said) a leak between the pump and the O ring on the fill probe. Check all connections back to the pump.

i woder if i have purchased a dodgy pump asi got it from airgunbbs forum second hand
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
jameswrx
You could wrap electrical tape around the hole in the fill probe to seal it and give that a pump, at least show you if it's the gun or the pump. But if the gun is saying 100bar and your not getting pressure on the pump then sounds like the pump or whip is at fault.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
ive just noticed the leak is coming from the Coupler Socket conected to the hose.no matter how tight it is it still leaks ,should there be an oring between them.
Attached to this post:
Attachments: WP_20160116_12_10_35_Pro.jpg (49.75 KB)
Edited by bcham, Saturday Jan 16 2016, 02:34 PM.
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
U need to put Ptf tape round the threads to seal it ;)
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Depending on the fitting you can use a dowty washer or if there's no shoulder ptfe tape on the threads.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
sorted now i used the dowty washer from the moisture trap on the pump. andnow im getting air in to the pistol but its leaking from the moisture trap slightly, so ive just ordered one of these 1/8bsp
http://www.ebay.co.uk/itm/121067075551
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
bcham
heres aigun worlds review.

http://www.sportsmk.co.uk/cat/26485/air-pistols-smk-air-pistols/victory-pistols/
Edited by bcham, Saturday Jan 16 2016, 09:44 PM.
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
Is it Mikey g doing the review
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
Dave G
Sounds daft but with all this shit going on with Gilles and airgun gear I'm going to hold off buying one till the out come is published pretty low bow by smk or order one from the EU
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Shame P10's and the like seems dearer in EU mate. I won't be boycotting SMK, just hope they do the right thing and either weigh Giles out or something.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
The polish shops will be cheaper than uk but can't remember fecking name will be on a cp1 thread
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
Dave G
http://gun.cz/31058-Vzduchova_pistole_SPA_PP700W_45mm/



Around £155 shop about in Poland ect prob lot cheaper
Edited by Dave G, Saturday Jan 16 2016, 10:29 PM.
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
I did email Selesia factory (prob who you're thinking?) but they said they weren't stocking them. Or certainly at the time they didn't have them.

I'll check there now.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
Look at cp1 multi shot at balistas cheap as chips perfect donor and multi shot only prob co2 wounded if u could seal and it a fill valve turn to pcp


http://www.balistas.com/air-pistols/spa-air-pistols/spa-cp10-cal.55mm/
Edited by Dave G, Saturday Jan 16 2016, 11:10 PM.
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Yeah, didn't pay much for my CP1-M from Selesia

Not a patch on the PP700W though IMO.

Just a shame it doesn't come with nicer grip and open sights.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
Krale have in stock but he original spa ones ;)
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
bcham
Dave G
Sunday Jan 17 2016, 06:05 PM
Krale have in stock but he original spa ones ;)

do you mean the ones with the wood grips,
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
sovjet
At krale it says end of february, they are out of stock at the moment too
Member Avatar
Dont edit
[ *  *  * ]
Quote Post Goto Top Offline Profile
hotdog
Dave G
Saturday Jan 16 2016, 11:06 PM
Look at cp1 multi shot at balistas cheap as chips perfect donor and multi shot only prob co2 wounded if u could seal and it a fill valve turn to pcp


http://www.balistas.com/air-pistols/spa-air-pistols/spa-cp10-cal.55mm/
A few have modded them to PCP on the Chinese airgun forum, although looks more trouble than it's worth. They're ok as a donor as they're easy to work on but quality is average. You can get the SMK version (slightly better finished) for £129 if you look around.
I'm considering making a carbon silenced shroud for mine, doubt I'll go to a PCP conversion though.
Member Avatar
Cricket
[ *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Picked up some walnut yesterday..

Posted Image

Posted Image

And this is rather special..

Posted Image
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Got two more bits but they're just sawn at the moment..

Colibri stock in English walnut and then one for the PP700 mini pup and enough for something for the P10 and spares!
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
bcham
make sure you post pics as you go on, been wandering if theres a way to mod a crosman stock to fit the pp700w No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Stormraider77
Getting a boner for one of these pistols now. No Avatar
Global mobile moderator always on the move 10-4
[ * ]
Quote Post Goto Top Offline Profile
jameswrx
Think the Colibri style is what I'm going to go for. Just with a different angle on the grip.

Posted Image

Might go for more of a cut out, not sure. Or maybe just a deeper detail cut out similar to the Colibri.

Posted Image

The pink dots show what I'm thinking for the cocking action. Drill a hole through the end of the pp700 cocking lever (so its reversible) and bolt a small alloy cylinder like the Colibri's cocking lever on to the side of the pp700 cocking lever. Just drill and tap the new cocking side lever and bolt through the pp700 lever.

What I'll do then is cut a groove in the stock so the new cocking action will be in a downward angled cocking motion with a slight arc with a pull back on a side cocking lever. This will be on the RHS of the stock as it will move when fired obviously!

Posted Image


There will also need to be a hex bolt each side of the grip to secure the action to the stock. This is going to require drilling and taping the hammer spring frame to accept a bolt, which can be a flat hex bolt like the Colibri counter sunk in the top of the grip. The original bottom fixing for the pp700 can also remain.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
Excellent James look forward to pics
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
bcham
it would look nice, with camo paint like the marauder woods walker. how do you remove the shroud, does it screw off No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Ash77
They sure do look nice. Very tempted to get one for a project.
Member Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
You started the stock yet James ???
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Not yet Dave, been too busy working!

Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Mr. Tackleberry
James, I am looking forward to seeing more. Great pictures, and amazing ideas. I wish I had your talent. No Avatar

Quote Post Goto Top Offline Profile
666
Hi James,

Any progress on this? I have just bought one this morning. Im wondering if some clever soul can get a design for 3d printing? Just a thought? Maybe with storage for pellets included etc in the butt end?

Pete
No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
jameswrx
Hoping to get it planed to thickness tomorrow. But I have loads on.

Best bet for a quick fix on these I reckon is to get a rat catcher stock and bond it to the pp700 grip.
Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
666
jameswrx
Tuesday Feb 9 2016, 08:14 PM
Hoping to get it planed to thickness tomorrow. But I have loads on.

Best bet for a quick fix on these I reckon is to get a rat catcher stock and bond it to the pp700 grip.
James,

That's a good idea but not my thing. Think I will do similar to you with the colibri style, I hope you dont mind. I'm going laminate on this one.

Pete

No Avatar
P12
[ * ]
Quote Post Goto Top Offline Profile
Dave G
Any update on these shop by me is selling the with longer barrel fitted seems a perfect bullpup / carbine option
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
jameswrx
Not seen the longer barrel ones Dave?

As I was saying to Ben in chat, chap that was/is sorting the initial thickness before I can start cutting lost his father and I don't want to push him as he's busy enough.

Member Avatar
The collector / colibri detective
[ *  * ]
Quote Post Goto Top Offline Profile
Dave G
http://www.aaronwheelergunsmith.co.uk/product/177-cal-4-5mm-22-cal-5-5mm-smk-pp700w-pcp-pistols-with-optional-upgrades/


Screw cut ect too
Member Avatar
More bad ass than Chumlee
[ *  *  *  * ]
Quote Post Goto Top Offline Profile
3 users reading this topic (3 Guests and 0 Anonymous)
Go to Next Page
« Previous Topic · All other Airguns · Next Topic »
Add Reply


A Blood Red World theme created by Canimia from Zathyus Networks Resources
